K521 - 1"

V42 Series Valves – AquaMatic / AqMatic – Common Configurations
Part Number Model Number Valve options Diaphragm/Seal/Disk NO NC SAO SAC LC PI
1″ VALVES
1070154 K521-X200-14000 Normally Open Buna-N / EPDM x
1070159 K521-X230-14000 Normally Closed Buna-N / EPDM x
1070158 K521-X201-14000 Normally Open, SAO Buna-N / EPDM x   x
1070157 K521-X202-14000 Normally Open, SAC Buna-N / EPDM x     x
1070155 K521-X210-14000 Normally Open, LS Buna-N / EPDM x       x
1070156 K521-X211-14000 Normally  Open, LS, SAO Buna-N / EPDM x   x   x
1070160 K521-X232-14000 Normally Closed, SAC Buna-N / EPDM   x   x
1071143 K521-X221-14000 Normally Open, PI, SAO Buna-N / EPDM x   x     x
1071112 K521-X200-24000 Normally Open FKM / FKM x
1071149 K521-X232-24000 Normally Closed, SAC FKM / FKM   x   x
1071117 K521-X200-54000 Normally Open Buna-N / FKM x
1071118 K521-X200-64000 Normally Open Buna-N / Butyl x
Approximate Ship Weight 2 Lbs
