AqMatic 1 Special Valve V42C-00SX-78175 Solenoid Valve Assembly

AquaMatic V42C-00SX-78175 – 1 Inch Special Valve – Special Solenoid – BUNA/BUNA/Hycar

AqMatic V42F-0000-00032 2″ normally open diaphragm valve. Cast iron construction for high-flow water treatment, filtration, and system control applications.

https://buy-aq-matic.com/product/aquamatic-v42c-00sx-78175-1-inch-special-valve-special-solenoid-bunabunahycar/

Description

The AqMatic V42C-00SX-78175 is a 1-inch cast iron diaphragm valve with a special configuration and custom solenoid setup, designed for systems requiring non-standard control behavior and modified internal porting.

This model is part of the V42 series, a metal-body diaphragm valve platform used across water treatment, filtration, and industrial fluid control systems. The V42 design uses a Y-pattern body that supports higher flow rates with lower pressure loss while maintaining reliable shutoff performance.

The 00SX designation indicates a special-order configuration, including drilled and tapped bosses and modified internal components. This allows the valve to integrate into systems with specific control requirements or legacy layouts where standard configurations will not align.

This configuration uses a Buna diaphragm with Buna seals and Hycar discs, supporting compatibility in water treatment and select chemical environments where mixed elastomer performance is required.

The valve is typically deployed in automated systems using stagers and stager controls, or alongside other V42 diaphragm valves in multi-valve assemblies where coordinated control is required.

$272.51

Expedite (5 Days to ship)

Only choose this option if you have talked to an agent who said it is available.

Product price: $272.51
Total options:
Order total:

Description

Model Number SKU
V42C-00SX-78175 1082043
Pipe Size Connectors
1 Inch Female N.P.T
Configuration Diaphragm, Seals & Disc
Special Valve BUNA N Diaphragm, BUNA N Seals & Hycar Discs
Internal Parts Bosses Drilled & Tapped
Special Order Boss #1
Solenoid / Float? Solenoid & Float Options
Solenoid Valve Special Solenoid Configuration
Solenoid Features Float Features
Special Solenoid Configuration

Key Features & Benefits

  • 1-inch V42C cast iron diaphragm valve for mid-range flow applications
  • 00SX special configuration supports custom porting, drilled bosses, and non-standard system integration
  • Special solenoid configuration designed for application-specific control requirements
  • Buna diaphragm with Buna seals and Hycar discs for compatibility across water and select chemical systems
  • Y-pattern body design supports higher flow rates with lower pressure loss
  • Separate control and flow chambers improve sealing reliability and protect internal components
  • Suitable for filtration, softening, and industrial fluid control systems requiring custom valve behavior
  • Can be integrated with stagers and stager controls for automated operation

Additional information

Weight 4.5 lbs
Dimensions 8 × 6 × 4 in
